The sturdy Metehe 45 profile is the highest profile of our selection, and it offers shape and load-bearing capacity for the roof. The narrow and straight box profile is produced with 0.45-0.70 mm colour-coated steel sheet. The product is suitable for industrial sites, shelters and warehouse buildings. Coating options PUR, PUR Matt and PVDF+ (technical warranty 50 years), HC25 (technical warranty 40 years) and PE (technical warranty 30 years). The product is also available with anti-condensation felt.
Profile dimensions roofing sheets dwg
Metehe Oy
tel: +358 207 639 640
myynti@metehe.fi
Metehe 45
| Application: | Roofing sheet, minimum inclination of roof 1:7 |
| Material: | Colour-coated 0.45-0.70 mm steel sheet |
| Dimensions: | Usable width 900 mm Total width ~ 970 mm Total height 42–45 mm depending on material thickness Standard length 100–13,100 mm |
| Installation: | With roofing screws from the base of the groove |
Please note that the colours are for reference purposes only and may differ from the sheet metal’s true colour tone. Please contact us and we will deliver a sheet metal colour sample of your chosen material.
Metehe Oy
tel: +358 207 639 640
myynti@metehe.fi
11 Spruce Green |
21 Light Grey |
22 Grey |
23 Dark Grey |
2H3 Anthracite |
29 Red |
30 Light Brown |
31 Brown |
32 Dark Brown |
33 Black |
34 Light Blue |
35 Blue |
36 Light Green |
37 Green |
40 Silver |
41 Dark Silver |
750 Brick Red |
